Numerical Control Pipe Beveling Machine

Get a Price/Quote

MOQ : 1 Set

Numerical Control Pipe Beveling Machine Specification

Voltage
380 V

Motor Power
5.5 kW (Main Drive)

Frequency
50 Hz

Connectivity Options
USB, Ethernet

Machine Type
CNC Pipe Beveler

Frame Type
Heavy-duty Steel Frame

Plastic Processed
N/A (Metal Pipe Processing)

Accuracy
0.1 mm

Features
High efficiency, precision beveling, easy to program angles, robust structure

Operating Temperature
0-45C

Drive
Servo Electric Drive

Model No
NC-PBM-2100

Cooling System
Water Cooling

Lubricating System
Automatic lubrication

Power Rating
5.5 kW

Noise Level
78 dB

Production Capacity
60-80 Pipes/Hour

Product Type
Numerical Control Pipe Beveling Machine

Technology
CNC (Computer Numerical Control)

Power Source
Electric

Operating Type
Automatic

Power
5.5 kW

Pressure
Hydraulic, Adjustable up to 10 MPa

Surface Treatment
Paint Coated

Dimension (L*W*H)
2100 x 1300 x 1600 mm

Weight (kg)
1800 kg

Color
Blue & White

Usage & Applications
Pipe Beveling for piping, pipeline fabrication, fittings, and preparation prior to welding

Ambient Humidity
85% RH

Software Update
USB upgrade capability

Data Storage
Program recipe memory capability

Control Panel
Touchscreen HMI

Cutting Tool Material
High-Speed Steel (HSS) / Carbide

Bevel Angle Range
0-60 (programmable)

Max Pipe Wall Thickness
25 mm

Maintenance Requirement
Low, with scheduled lubrication points

Bevel Shape
V, J, U, double V (per program)

Operator Skill Level
Semi-skilled to skilled

Installation Type
Floor Mounted

Safety Features
Emergency stop, interlock, overload protection, safety guards

Pipe Diameter Range
50 - 600 mm

Tool Change System
Quick-change tool holder

Clamping System
Hydraulic Automatic Clamping

Numerical Control Pipe Beveling Machine Trade Information

Minimum Order Quantity
1 Set

Supply Ability
Set

Delivery Time
45 Days

Main Export Market(s)
Asia

Main Domestic Market
All India

About Numerical Control Pipe Beveling Machine

Numerical Control Pipe End Beveling Machine is commonly used for beveling pipes with thick walls and machining U or V shape bevels. Our professionals use high-quality raw materials and advanced technologies to create the equipment we offer. Furthermore, our offered machine is put through a series of tests by quality controllers to assure its functionality.

Unlock Precision and Efficiency with the Numerical Control Pipe Beveling Machine

Introducing our cutting-edge Numerical Control Pipe Beveling Machine, the pinnacle of precision and efficiency in pipe fabrication. With its advanced features and exceptional performance, this machine is designed to revolutionize the beveling process, delivering flawless results that meet the highest industry standards.

The Numerical Control Pipe Beveling Machine offers unmatched versatility, accommodating various pipe sizes and materials. Whether you're working with stainless steel, carbon steel, or other alloys, this machine adapts effortlessly to your specific beveling requirements. Its adjustable settings and state-of-the-art technology ensure consistent and accurate bevels every time.

Powered by advanced numerical control capabilities, our machine streamlines the beveling process, enhancing both precision and efficiency. With precise control over key parameters such as bevel angle, cutting speed, and feed rate, operators can achieve optimal results without any guesswork. Say goodbye to manual errors and hello to flawlessly beveled pipes.

Safety is our utmost priority, and the Numerical Control Pipe Beveling Machine is designed with comprehensive safety features. Equipped with protective enclosures, emergency stop buttons, and automatic shutdown mechanisms, it ensures a secure working environment for operators. You can have peace of mind knowing that your team is protected while operating the machine.

What sets our Numerical Control Pipe Beveling Machine apart is its exceptional efficiency. By automating the beveling process, it significantly reduces production time and boosts overall productivity. With high-speed cutting capabilities and consistent beveling results, you can meet tight deadlines without compromising on quality, empowering your business to thrive.

Investing in our Numerical Control Pipe Beveling Machine is a strategic choice for success in pipe fabrication operations. With its cutting-edge technology and precise performance, you gain a competitive edge in the market and deliver superior bevels that surpass expectations. Its exceptional reliability and efficiency enable you to take on complex projects and build a reputation for excellence.

Don't settle for subpar beveling machines. Upgrade to our Numerical Control Pipe Beveling Machine today and experience the transformative impact it has on your pipe fabrication projects. Contact us now to learn more about this innovative machine and how it can revolutionize your beveling operations for the better.

Numerical Control Pipe End Beveling Machine Features:

It offers bevel cutting, which involves cutting a pipe with other tools like a band saw and then machining each bevel.
The numerical control pipe end beveling equipment has excellent bevel quality.
Suitable for heavy wall thickness pipe
Very good, surface finish quality
Numerical Control Pipe End Beveling Machine has a beveling speed of 5 minutes per pipe bevel
Online performance is good with the numerical control pipe end beveling machine

Applications:

The numerical control pipe end beveling machine is used to create U or V shape bevels for a variety of pipes with thick walls. Cutting off the pipe with another piece of equipment, such as a band saw m/c, and then machining a bevel for each pipe.

Numerical Control Pipe End Beveling Machine Specifications:

The pipe diameter varies from DN600 to DN1500
Carbon steel, alloy steel, stainless steel, cryogenic steel, etc. are the materials used
Bevel Shape: U, X, V, and double V
Stepless speed control and variable frequency is provided
The bracket system is adjustable with screw lifting
Workpiece is clamped by hydraulic cylinder and centering automatically

Advanced Precision and Versatility

Engineered for a range of pipe diameters and thicknesses, the NC-PBM-2100 utilizes CNC control for accurate beveling with programmable angles and selectable bevel shapes such as V, J, U, and double V. The touchscreen HMI and PLC interface enable straightforward recipe storage and modification, enhancing repeatability across projects.

Efficient Operation and Easy Maintenance

Hydraulic clamping, automatic lubrication, and a quick-change tool holder facilitate seamless process flow and reduced downtime. Scheduled lubrication points and robust overload protection minimize routine maintenance while ensuring safe, dependable operation in demanding industrial settings.

Safety and User-Friendly Design

Safety remains paramount with emergency stop functions, interlocks, overload protection, and protective guards provided. The machine is designed for floor mounting, allowing semi-skilled or skilled operators to manage production efficiently with minimal risk and noise levels under 78 dB.

FAQs of Numerical Control Pipe Beveling Machine:

Q: How does the NC-PBM-2100 achieve precision pipe beveling?

A: The machine uses CNC technology paired with a servo electric drive and touchscreen HMI, enabling users to accurately program bevel angles (0-60) and select from various shapesV, J, U, or double Vachieving 0.1 mm accuracy for each cut.

Q: What types of pipes and wall thicknesses can this machine bevel?

A: It is suitable for metal pipes with diameters between 50 and 600 mm and wall thicknesses up to 25 mm, making it ideal for pipeline fabrication and preparation prior to welding.

Q: When is program recipe memory especially beneficial?

A: The recipe memory function allows operators to quickly recall and deploy saved beveling procedures for different pipe jobs, reducing setup time and ensuring consistent quality between batches or repeat orders.

Q: Where should this machine be installed for optimal performance?

A: Designed as a floor-mounted system, the NC-PBM-2100 operates best in industrial workshops with ambient humidity 85% RH and temperature between 0-45C, suitable for manufacturing, fabrication, and job shop environments.

Q: What is the process for changing cutting tools?

A: Tool changes are efficient due to the quick-change tool holder. Operators can swiftly exchange between high-speed steel (HSS) and carbide cutting tools without extensive downtime, supporting continuous production.

Q: How does the hydraulic clamping system improve usability?

A: The hydraulic automatic clamping reliably secures pipes of varying diameters, ensuring safe, stable machining. The adjustable pressure (up to 10 MPa) allows flexibility for different pipe sizes and materials.

Q: What are the core benefits of using this CNC pipe beveler?

A: Key advantages include high efficiency (processing 60-80 pipes per hour), precise and easy angle programming, robust safety features, low noise, USB/Ethernet connectivity for upgrades, and reduced maintenance due to automatic lubrication.
